| Cabinet Material | Cold-roll steel 1.5mm–2.5mm, anti-dust, anti-vandal |
| Monitor | TFT LCD, 250cd/m² brightness, 1000:1 contrast, 40,000+ hrs lifespan |
| Touch Screen | IR/SAW/Capacitive, high precision, tempered glass, 50M+ touches durability |
| PC System | Industrial-grade PC (Dual Core / i3 / i5 / i7), 2–8GB RAM, 500GB HDD |
| Card Reader | Magnetic/IC/RF card support, encrypted pinpad (IP65) |
| Bill Acceptor | Cashcode with 96%+ validation rate, up to 1000-note capacity |
| Coin Acceptor | 32 coin types, counterfeit detection, 2 coins/sec |
| Printer | Epson thermal printer, 80mm width, 150mm/s print speed, autocutter |
| Power Supply | 110–240V, UPS backup 3–20 mins, digital AC supply |
| Optional Parts | Barcode scanner, passport reader, A4 printer, webcam, RFID, advertising screen |
Software support of touch screen outdoor kiosk
Operating System: Windows 7 / XP / Linux (license not included)
Supported Drivers: Touch panel, printer, cash devices
Kiosk Application Options: Payment software, queue management, visitor check-in, ticketing system
Remote Monitoring: Optional support for system health monitoring and remote updates |  |
Applications and customizations of touch screen outdoor kiosk
ApplicationsBanks and ATMs Hospitals and Clinics Subway and Railway Stations Parking Lots Shopping Malls Theaters and Cinemas Government and Property Management Areas Outdoor Info or Ticketing Booths
| Customization OptionsScreen Size: 17", 19", 21.5", 24", 27", 32", 43", 49", 55", 65" Touch Technology: IR / SAW / Capacitive Color & Logo: Customizable on request Peripheral Devices: Choose based on application (e.g. card readers, scanners, printers, cameras) Mounting Style: Freestanding, wall-mounted, or customized enclosure design OS and Software: Based on customer’s system or LKS standard integration
|
Advantages of touch screen outdoor kiosk
Weatherproof and Durable: Designed with IP65-rated waterproof and dustproof enclosure, ideal for harsh outdoor conditions like rain, dust, or snow.
19” High-Brightness Display: Equipped with a 19-inch TFT LCD screen offering vivid visuals and sunlight readability.
Sensitive Touchscreen: Supports capacitive or infrared multi-touch technology for smooth and responsive user interaction.
Integrated Card Reader and Printer: Built-in IC card reader and thermal printer make it perfect for ticketing and payment applications.
Highly Customizable: Available in multiple sizes and configurations, with options for external devices like cameras, QR scanners, and more.
Reliable Performance: Runs on industrial-grade PC with support for Windows or Linux, enabling 24/7 stable operation with remote management options.
FAQs about touch screen outdoor kiosk
Q1: What is a touch screen outdoor kiosk and how is it used?
A touch screen outdoor kiosk is a self-service terminal designed for outdoor environments. It features a waterproof and dustproof body, a high-brightness touch display, and often includes devices like printers or card readers. It is widely used in public spaces for ticketing, information services, and self-check-in applications.
Q2: Can the touch screen outdoor kiosk operate in extreme weather?
Yes, our touch screen outdoor kiosk is built for year-round outdoor use. With an IP65-rated enclosure, it withstands rain, dust, heat, and cold. It functions reliably in temperatures from -20°C to 60°C, making it suitable for use in outdoor transportation hubs, city centers, theme parks, and more.
Q3: What screen sizes are available for the touch screen outdoor kiosk?
The touch screen outdoor kiosk comes in a wide range of sizes from 17” to 65”. The 19” model is compact and cost-effective for simple tasks like ticket printing. Larger models are suited for digital signage, advertising, or interactive directories, depending on your application needs.
Q4: What software runs on the touch screen outdoor kiosk?
Our touch screen outdoor kiosk supports both Windows and Linux OS. It comes with basic drivers for touch, card reading, and printing. Additional software like payment systems, queue management, or customer-facing apps can be installed based on your requirements. Remote monitoring software is optional.
Q5: Is the touch screen outdoor kiosk secure for public payments?
Yes, the touch screen outdoor kiosk is equipped with secure components like encrypted card readers, tamper-resistant locks, and optional surveillance cameras. It supports PCI-compliant payment modules and offers secure data transmission, making it safe for financial or identity-sensitive transactions.
Q6: Can I customize the touch screen outdoor kiosk for my project?
Absolutely. The touch screen outdoor kiosk is fully customizable in terms of size, housing color, logo, touch type, and add-on devices. Whether you need a printer, scanner, NFC reader, or facial recognition camera, we can tailor the kiosk to match your application and branding.
